Logging Truck

  • 1
  • 2
  • 3

Contact Now

Performance&Characteristic:

Logging drawworksselects second-class chassis,retrofitting drawworksoperation cabin etc. oil special devices and equipment on it, As per integrated oil drawworks3500 meters specifications, 5000 meters specifications, single (double) drum structure, mechanical (hydraulic) drive , state regulations, general technology, standard configuration, technical agreement to design and produce product.

It is used for loading ground equipment and downholetool for petroleum logging , perforation, production operation, providing a good workplace for operator. It consists of drawworksmechanism drawworkstransmission drive, coiled coil, power supply and lighting system downholetool and air-conditioner etc. it can be designed and fixed according to the request of the user.

Specification:

Engine Model

OM501LA.Ⅲ/15

Engine power (kw)

235

Engine capacity

11946

Engine manufacturers

Daimler Group Germany

Engine Trademark

Combustion types

diesel oil

Dimensions
(Length×width×height)(mm)

9740×2500×3920

The total mass (Kg)

27850

Chajingu / departure angle (°)

23/13

Front/Rear Overhang
(mm)

1440/2450

Wheelbase (mm)

4500+1350

Axle-load

6530
21320

Shaft number

3

Maximum speed (km/h)

85

Oil Consumption

Pcs of Spring

3/4

Several tire

10

Tire specifications

12.00R20

Front Tread

2034

Rear Tread

1804/1804

Overall Mass(kg)

27720

Criteria

GB3847-2005
GB17691-2005
